Precision Grinding Robot Cell QY-D750
This product is developed for precision grinding of small-to-medium castings.This product uses a general-purpose six-axis industrial robot, with a composite grinding tool mounted at the robot end. Equipped with a 3D vision system and a grinding monitoring system, it enables flexible processing of gates, risers, residual roots, flash, and gas hole pin remnants on small-to-medium castings. This product features high efficiency, high precision, and high flexibility. Typical applications include hydraulic pumps, differential housings, turbine housings, brake discs, brackets, valve bodies, manifolds, and more.
Show All
share：
Technical Parameters
| Model | QY-750 |
| Residual Grinding Tolerance | ≤ 0.5 mm |
| Grinding Removal Efficiency | 30 mm/s (risers and gates), 45 mm/s (stubs), 60 mm/s (flash) |
| Workpiece Dimension | < Φ750 mm × 500 mm |
| Workpiece Weight | ≤ 500 kg |
| Workpiece Material | Cast Iron |
| Fixture Versatility | Compatible with multiple workpiece models |
| Fixture Clamping Method | Automatic clamping or manual clamping |
| Equipment Dimensions | 4500 mm × 2850 mm × 3000 mm |
| Equipment Weight | 5 t |
| Robot Body | ABB/KUKA Industrial Robot |
| Robot Count | 1 unit |
| Robot Axes | 6 axes |
|
End effector |
Grinding tool (Robot hold tool) |
| Robot Payload | ≥ 200 kg |
| Robot Repeat Positioning Accuracy | ± 0.06 mm |
| Vision System | 3D Vision System (Standard) |
| Grinding Force Monitoring & Control System | Grinding force monitoring and control system (Standard) |
| Tool System | Rigid-flexible grinding tools (Standard) |
| Tool Magazine System | Tool magazine with automatic tool change function (Optional) |
| Information System | EMS & API Interfaces provided (Standard) |
| Cooling System | Cooling Station (Standard) |
| Hydraulic System | Hydraulic Station (Standard) |
| Power System | Electrical Control Station (Standard) |
| Control System | Control Cabinet (Standard) |
| Dust Removal System | Dust removal interface provided (Standard) |
