Precision Grinding Robot Cell QY-CS3600 (Fixed)
This product is developed for precision grinding of large castings.This product is equipped with multiple general-purpose six-axis industrial robots, with composite grinding tools mounted at the robot ends. Integrated with a 3D vision system, a grinding monitoring system, and an automatic transport system, it enables flexible processing of gates, risers, residual roots, and flash on large castings. Through 3D vision algorithms, the robots can overcome challenges such as large casting deformation and imprecise positioning. Multiple fixed-type robots working in coordination with the automatic transport system can expand the processing range, significantly improving grinding efficiency and production efficiency. Typical applications include machine tool bases, large diesel engines, and more.
Show All
Technical Parameters
| Model | QY-CS3600(Fixed) |
| Residual Grinding Tolerance | ≤ 0.5 mm |
| Grinding Removal Efficiency | 30 mm/s (risers and gates), 45 mm/s (stubs), 60 mm/s (flash) |
| Workpiece Dimension | < Φ3600 mm × 500 mm |
| Workpiece Weight | ≤ 5000 kg |
| Workpiece Material | Cast Iron |
| Fixture Versatility | Compatible with multiple workpiece models |
| Fixture Clamping Method | Automatic clamping or manual clamping |
| Equipment Dimensions | Customized as needed |
| Equipment Weight | Customized as needed |
| Robot Body | ABB/KUKA Industrial Robot |
| Robot Count | Customized as needed |
| Robot Axes | 6 axes |
|
End effector |
Grinding tool (Robot hold tool) |
| Robot Payload | ≥ 200 kg |
| Robot Repeat Positioning Accuracy | ± 0.06 mm |
| Vision System | 3D Vision System (Standard) |
| Grinding Force Monitoring & Control System | Grinding force monitoring and control system (Standard) |
| Tool System | Rigid-flexible grinding tools (Standard) |
| Tool Magazine System | Tool magazine with automatic tool change function (Optional) |
| Information System | EMS & API Interfaces provided (Standard) |
| Cooling System | Cooling Station (Standard) |
| Hydraulic System | Hydraulic Station (Standard) |
| Power System | Electrical Control Station (Standard) |
| Control System | Control Cabinet (Standard) |
| Dust Removal System |
Dust removal interface provided (Standard) |
